New Features:

• Support for FLIR M300 Series cameras dual-stream visible and thermal payloads. Both visible and thermal video streams can now be viewed simultaneously across split-screen or multiple displays
• Fishidy Sync Support
• Expanding square SAR pattern added
• Support for AIS text messaging with AIS5000
• Victron battery management app
• iTC-5 calibration of depth, speed and wind sensors from the MFD
• Additional sailing polars added to the library
• Arabic keyboard support

Bug fixes:

• Fixed an issue with SiriusXM lightning strikes drawing at certain ranges
• Signal-to-noise issues fixed for internal Axiom and Axiom Pro sonars
• Incorrect Engine trim/tilt data and tank instancing resolved

Bug fixes:

• Multiple Data Source selection on the AXIOM MFD was being blocked if certain products were connected (i.e. if an ITC-5, Converter, Actisense or Fusion was in the system)
• When using AXIOM XL Video In/Touch out, we have improved the touch output commands when a finger is held down on the AXIOM screen

Changes to .zip file contents since this release:

• The MFD Download is continuously having the latest ISO files added, so that you get the latest system product upgrades

New Features:

• New LightHouse3 Apps - www.raymarine.com/multifunction-displays/lighthouse3/lighthouse-apps
  • BUOYWEATHER
  • Worldwide Coastal and Offshore Weather
  • SHADOW-CASTER
  • LED Underwater and Vessel Lighting Control
  • PREDICTWIND & OFFSHORE
  • Provide Weather Routing and Departure Planning
• M132/M232
  • Video stabilization via AR200 augmented reality mode

  • Thermal camera test and calibration via MFD
• Advanced Sailing Tools
  • New RACING chart mode selection
  • 'Race Start' in left pop-in Side Bar
  • Race Timer enhancements
  • Toggle the time by 1 minute intervals
  • Sync and adjust by 1 minute intervals
  • New Start Line feature
  • Easily Ping or Hot Spot each end of the start line. Can also swap ends for up or down wind starts
  • Laylines now appear on Start Line, once Race Timer has started
  • New Data Items - i.e. Time to Burn, Line Bias, Distance to Line
  • New race dashboard - for Race Start (not standard sailing dash)
  • New data overlays on the screen (TWS, TWA, TWD, AWS, AWA)
  • New vessels in POLAR DATABASE from polars@raymarine.com
• SiriusXM SR200 support
• Full SiriusXM Marine Weather and Satellite Radio support
• Network-wide viewing and control
• New Canadian Marine Zone forecast
• First Responder features (with the AIS5000)
• PDF Viewer
• Upgraded DJI SDK from v4.9 to v4.10
• MFD Diagnostic enhancements
  • IP Cameras now shown in a network scan
  • New menu option to Record NMEA2000 bus data direct to uSD card
  • Improved NMEA2000 descriptions/raw data viewability

Bug fixes in v3.10:

• Axiom & Axiom-Pro intermittently showing 'No Transducer Connected'
• Axiom LH3.8 & Fusion audio FM stereo channel segment graphics overlapping the change arrows
• Dashboard app causing MFD to reboot (Certain Split screen app configuration)
• Navionics plotter sync not working
• Estonian language selected but shows English
• Race Timer on Dashboard stuck on 3h
• Quantum Radome and wired adaptor software update fails when AXIOM MFD running v3.9.46
• Camera motion menu missing when M132 is connected
• Cannot change number of tanks after MFD boat wizard completed
• Axiom-RV can re-boot when adaptor cable A80491 is connected
• Yamaha fuel tank is erased from system
• Navionics last update date is reporting incorrectly
• Intermittent Raynet data sharing from master MFD to repeaters
• LNC2 'show soundings' toggle does not work
• LNC2 spot soundings units selection now global
• With system units set to km the predicted area of danger is show incorrectly
• When filtering Static Targets or showing Crossing Targets only, the MFD was still showing All potential targets
• Minor Drone control improvements

Changes to .zip file contents since this release:

• The MFD Download is continuously having the latest ISO files added, so that you get the latest system product upgrades

New Features:

• UAV Compatibility
• New Model integration
• DJI Mavic 2 Pro / Mavic 2 Zoom
• Laylines - active in sailing only
  • Up and Down Wind Angles
  • Distance to layline (distance to tack)
  • Time to layline (time to tack)
  • Sailing distance to WP (total for both legs)
  • Sailing time to WP (total for both legs)
  • Target boat speed
  • % of target boat speed achieved
• New Sailing Features
• Steering guidance
• Updated sailing dashboard
• New Sirius XM
• SR200 support
• AXIOM range only from LH3.9
• Audio control across all networked MFDs
• Weather control via Weather mode on data Master only
• New ClearCruise Augmented Reality features
• ClearCruise AR is now compatible with the FLIR M132 and M232 Thermal Cameras
• Non IP AR cameras can now be disabled in the menu
• Yamaha Command Link / Command Link Pro
• Lighthouse3 v3.9.46 Setup
• Configure Yamaha Dashboard page in Homescreen
• Settings and Boat Details
• Select Yamaha as engine manufacturer
• Configure Yamaha display - Twin, Triple, Quad...
• Select number of Batteries
• Select number of Tanks
• Compatibility: Yamaha In-Line F200 outboards and 4.2L V6 Offshore, all V8 F350 models and new F425 (V8 5.6L) in twin, triple or quad configurations
• Eliminates need to fit Yamaha CL7 7' display
• Requires NMEA2000 Gateway
• P/N: 6YG-8A2D-00-00
• Important: Helm Master functions (Fish Point, Drift Point and Stay Point) and joystick functionality require CL7
• SONAR - New Pinch to Zoom and Range Shift
• Pinch out to initiate SONAR Zoom
• Infinite zoom increments up to 8x the range
• Works in auto and manual range
• Range Shift
• Manual range to bottom of desired focus area
• Pinch (out) to initiate SONAR zoom on focus area
• Easily range deeper if area of interest shifts down
• Radar Sector Blanking
• Define up to 2 sectors inside which no Radar data will be transmitted
• Avoid transmitting into nearby object that may be sensitive to microwaves (e.g. Sat TV) or cause for poor performance (e.g. Metal Radar mounts)
• Blanking occurs on the main Radar and Radar overlay on a chart
• *Only available on Magnum Radars
• Video Playback
• View Video files in MyFile locations
• Open or Delete
• Play/Pause, FF, RW
• **there is no edit functionality for Video files currently. Therefore, you cannot move the stored file location or rename via the MFD
• Tank naming and Sender Calibration
• New 10 Tank full screen and 8 Tank split screen layouts
• New Realbathy™
• Personal SONAR Map generator
• Real-time 1 foot contours
• Variable overlay transparency
• Safe depth colorization

Bug fixes:

• Center Starboard engine graphic on Quad Engine Layout incorect - now fixed
• CZone Dashboard 'Configuration Conflict' Message - fixed
• CZone Imported mew configuration not used until system power cycled - now fixed
• CZone display conflict when CZone display in system - now fixed
• Cartography version is not reported on networked MFDs - now fixed
• Waypoints could lose their time stamp when used in a route - now fixed
• Waypoint sort issues - fixed
• Shallow water fishing range alarm increments incorrectly - now fixed
• Diagnostics list not updating with product info - fixed
• AXIOM intermittently failing to upgrade to latest software (v3.8.105) - now resolved
• Improvements to upgrading an AXIOM Pro/AXIOM XL via memory card

Changes to .zip file contents since this release:

• The MFD Download is continuously having the latest ISO files added, so that you get the latest system product upgrades

Bug fixes:

• Now correctly displays Spot Sounds when using LightHouse NOAA US vector charts
• Resolves an issue where Rockford Fosgate control via the MFD was intermittently lost.

Changes to .zip file contents since this release:

• The MFD Download is continuously having the latest ISO files added, so that you get the latest system product upgrades

New Features:

• CZone Digital Switching, Control and Monitoring
• JL Audio Media Master Remote Control
• Search and Rescue Patterns
• Collision Avoidance Predicted Area of Danger Overlay
• Dynamic Target Intercept Calculations
• Electronic Chart Synchronization
• LightHouse NC2 Electronic Chart Base Map
• LightHouse Charts Selectable Depth Coloring
• LORAN-C TD Support
• LightHouse Apps Manager (AXIOM family exclusive)
• Rudder Bar visable in Chart App 'Sidebar' - even with Pilot control disabled
• HONK alarm output & Anchor alarm on SeaTalk^ng

Bug fixes:

• Waypoint import improvements
• RayControl connection improvements with certain Android Versions
• Various AR overlay improvements
• New Navionics Library - To stabilize intermittent performance issues
• Data Backup now working in Finnish language
• Quantum Radar 'Connection Lost' issue improved on AXIOM/DV/RV
• Route/ Track/ Vector width change working as expected
• Fuel Manager - 'Fuel Used' at Trip Month now working as expected
• GPS Priority - MFD now uses internal GPS as lowest priority

Changes to .zip file contents since this release:

• The MFD Download is continuously having the latest ISO files added, so that you get the latest system product upgrades

New Features:

• AR200 Augmented Reality support
• ClearCruise Target Range implemented when using M132 or M232 Cameras
• Seakeeper Integration Application
• Mazu-Marine mSeries Sentry System
• Backup and Restore feature implemented
• Note:
  • Saving of Digital Switching pages are local to each display
  • Custom Splash Screens are not Backed up

Bug fixes:

• Czone/VesselView could cause an MFD Crash - now resolved
• Retention of Chart Range throughout exiting the chart app - now resolved
• Navionics changes:
• Navigation Aids layer now defaulted to ON for the fishing chart
• Additional Wrecks menu item (no longer used) removed
• Resolved the inverted slider for aerial photo opacity/transparency
• Fishing range highlights now defaulted to OFF for the fishing chart
• Waypoint names retained when a route is imported from GPX file
• Date used for Tide information could be incorrect - now resolved
• Quantum fixs:
  • Found an issue where the W3 board could have a missing S.N. preventing it from being s/w upgraded. V3.7.70 re-programs the S.N. if it is missing.
  • Resolves an issue where multiple presses of the Off Key from the Radar app, causes a crash.

Changes to .zip file contents since this release:

• The MFD Download is continuously having the latest ISO files added, so that you get the latest system product upgrades

New Features:

• Initial Release for AXIOM XL 22' hardware

Bug Fixes:

• MOB can trigger loss of HDMI output - resolved
• Touch Screen response improved with salt water spray
• FishFinder Simulator has been improved to show SONAR data on non-SONAR MFDs
• BlueTooth Sound Sync has been modified with HDMI output

New Features:

• Unmanned Aerial vehicle (UAV) integration support*
• DJI Mavic Professional
• DJI Mavic Professional Platinum Edition

Initial Release for AXIOM XL 24' hardware

Bug Fixes:

• Intermittent green screen SONAR
• Digital Switching Alert - alarm crash
• Digital Switching Alert - Momentary Button Down - Trigentic Firmware update v1.0.164

Note: RVX1000 requires new software (v3.6.32) to maintain MFD compatibility

New Features:

• LightHouse Apps*
  • Lumishore Lights App
• Audio App
  • Fusion Apollo support (770 and SRX400)
  • SR150 Audio for SiriusXM
• Bluetooth Alarm support*
• Demo movie
  • Plays from MicroSD card when in Simulator mode, after 60 seconds of inactivity
• PDF Viewer
  • PDF Documents read from MicroSD card
• Sonar RVX1000 enhancements
  • Supports RVX1000 error messages
  • Adds RVX1000 Sonar channels to the auto depth prioritisation model
• NMEA2000

  • Cummins C Command ED-4 electronics support for Remote Digital Alarm acknowledgement
  • PGN 127506 support (DC Detailed Status)
• RayNet

  • Navionics Charts networking enhancements between displays

Bug Fixes:

• Ground Log/Trip Reset option not resetting values
• Importing of .GPX files improved
• GPS filter not working correctly
• Not able to turn off/hide the Safety Distance ring
• Network Diagnostics information missing products
• Digital Switching alerts improved

• Initial Release for AXIOM XL 16' hardware
• Recommended version for Magnum Radar compatibility
• Recommended version for RVX1000 SONAR compatibility

• LightHouse Apps*
  • Netflix
  • Spotify
  • GRIBview Weather App
• Chart additional features
  • Find Nearest
  • Tides Mode - tide and current graphs
• Bluetooth Audio Out*

  • Stream LightHouse 3 Entertainment App's

• Fuel Manager
  • Fuel range and economy settings
  • Honda ECO mode

Enhancements:

• Alarm Enhancements
  • Active alarm 'Homebutton' alert
  • Alarm history
  • Digital Switching alarm selection
• Radar Enhancements
  • Support for Quantum 2 Doppler
  • Support for Digital Radar Software Upgrades
• Custom Startup Splash Screen*
• Shared Brightness Group Control

Bug Fixes:

• Fusion Power Off Issue
• Intermittent Navionics Chart Networking Issue
• Tide Time Offset Issue
• CP370 Selection Issue
• Import GPX files

• Radar enhancements
  • Enhanced AIS Target Overlay in Radar Mode
  • Radar True Trails
  • Radar ARPA Auto Target Acquisition
  • Quantum Software Updates Supported
• Weather Mode & SiriusXM SR150 Receiver
  • Support for SiriusXM SR150 receiver in new Weather Mode in charting app
  • Overlay weather data directly on your preferred cartography
  • Select and Animate weather layers from side menu
• Sonar Upgrades
  • RealVision^TM 3D Historical Sensitivity
  • Disable All Sonar
  • Depth & intensity Scale for 3D
  • Smooth Sonar Range Transition
• Navionics additional features
  • Plotter Sync
• Other Updates
  • Networked compatibility with eS and gS Series MFDs running LH3 v3.3.170
    • AXIOM or AXIOM-Pro set to Master
  • Supply Voltage data
  • Enhanced Diagnostics
  • Camera App - Cycling removed from v3.3 and planned to be reinstated in later version
• Various Bug fixes and improvements

• Improvements to the Wi-Fi firmware in all AXIOM Pro models.
  • No Change to AXIOM RV or AXIOM DV MFDs.

• Adjusted Backlight parameters at initial startup, for AXIOM Pro models

• Addressed satellite acquisition and GPS fix issue in select AXIOM models

• Initial Release for AXIOM Pro Models
• New features for all AXIOM models:
  • Wireless Display (Miracast) Streaming
  • Fusion Audio integration (CAN interface only)
  • Navionics Features:

    • Dock-to-Dock Autorouting (Autoroute to Here)*
    • Sonar Logging & SonarChart Live*
    • Panoramic Photos and Pilot Book (Platinum+ features)
    • Fishing Range and other advanced map features*
    *requires Freshest Data subscription
  • C-MAP integration
    • Essentials & 4DMAX/4DMAX+, Raster & Vector charts
    • Easy Routing (Autoroute to Here)*
    *requires C-MAP 4DMAX/4DMAX+ card
  • Sounder
    • RealVision 3D Nearby Waypoint Display
    • Expanded color palettes
    • Reverse Port/Starboard image Correction for certain step mount installations
  • Ability to upgrade STng Peripherals
    • Supports all ST^ng ISO files currently online
  • New Languages - Croatian, Czech, Malay and Slovenian
  • Bug fixes

• Direct Control from the MFD of Evolution Autopilots
• Sonar Enhancements
• Scrollback - 2D and 3D
• Sensitivity History
• GPS Tracks in 3D
• 3D Waypoint placement
• Mobile App. Support – RayView / RayControl / RayRemote (with updated App’s)
• RMK-10 Full network multi-unit control
• Bug fix - GPS status No Fix on repeater
• Additional bug fixes
• Additional Languages:
• Arabic
• Brazilian Portuguese
• Greek
• Icelandic
• Indonesian
• Japanese
• Korean
• Latvian
• Lithuanian
• Russian
• Simplified Chinese
• Traditional Chinese
• Vietnamese

• Changes to SONAR Y-Cables:
  • Allows ping on an Airmar Conical transducer when a Y-Cable is installed and Conical is not being viewed
  • Supports the DVS+Airmar Y-Cable (A80493 or A80486) that may be installed
  • Provides the ability to show all the SONAR channels available when using a Y-Cable
• Fix for a Language crash (GPS screen/Alarm dialogue)
• Fix for Autopilot Goto/Goto allowing an unacknowledged turn (not applicable to Evolution pilots).
• Allows the correct number of decimal places to be set in a Digital Switching page

• Initial Release for AXIOM 7DV SONAR unit
• Update for all networked AXIOM units (all networked units should be running the same version)

• Initial Release for AXIOM RV units
• Update for non-sonar unit network compatibility with RV units (all networked units should be running the same version)

v3.0.40

• Initial Release
